(HC-FSX90) Female SAE 45° - Swivel - 90° Elbow (FSX90-10-12)

(HC-FSX90) Female SAE 45° - Swivel - 90° Elbow (FSX90-10-12)

Replaces:
HY10-12FA90T Dayco
179HY-12-10 Miscellaneous
Crossed From:
SW08528 A&I

Specifications:
Dimension A (1) 0.625"
Dimension B (2) 3.720"
Dimension C (3) 2.500"
Dimension D (4) 1-1/8"
Dimension E (5) 1.830"
Dimension F (6) 1-1/4"
Hose Inside Diameter 5/8"
Replaces Dayco # HY10-12FA90T
Thread Size 1-1/16 x 14

This is a special order item. Special order items can take up to 3 to 5 additional days to arrive. If you have any questions regarding availability or processing time, please email us at chalmersind.questions@gmail.com.
